St. Catharines Pattern Limited
If you are looking to get models and prototypes made using high quality equipment, then visit St. Catharines Pattern Limited. With a staff of 12 (including office staff) we are always ready to meet or exceed your expectations. Our production team is composed of tradesmen, all of which are either patternmakers, machinists or apprentices.

We are housed in a modern 8,000 square foot building, close to major highways. We have plenty of manufacturing equipment for you to choose from to get anything from a single prototype to a large volume of models.

We have proudly maintained an ongoing program of apprentice training during the past 30 plus years that we have been in business.

The following is a list of our manufacturing equipment:

  • 4 CAD/CAM Workstations (SURFCAM/SolidWorks)
  • 7 CNC Mills
  • 1 CNC Lathe
  • 1 EDM Sinker
  • CMM Inspections
  • 3 Milling Machines
  • 2 Engine Lathes
  • Fully Equipped Wood Shop
You can supply your information through:

  • Blue Prints
  • CAD Files
  • Sample Parts

CAD/CAM Design

Work stations:
  • SURFCAM (4 Seats)
  • SolidWorks (2 Seats)
  • AutoCAD

We can download your files via:

Preferred file formats:

  • Drawing Files for AutoCAD (.dwg .dxf)
  • Surface Files for SURFCAM (.dsn .igs .x_t)
  • Solid Files for SolidWorks (.prt .sldprt .igs .step .x_t)


* We are ITAR certified
* We are in the final stages of ISO

Contact Us
Quotes are turned around in 1-2 days.
Contact us and we will be pleased to show you our facilities.

St. Catharines Pattern Limited
26 Export Ave.
St. Catharines, Ontario, Canada
L2M 7P2
Phone: 905-684-2111
Fax: 905-682-1481

St. Catharines Pattern Limited Map

Located in the heart of the Niagara region, we are close to major shipping routes. Just a short distance away from the Canada / U.S. border for ease of importing and exporting.
